roller door roll forming machine
Model: HX- Shutter Door Machine
Payment: TT,30% deposit,70% balance before shipment
Voltage: 380V 50HZ 3Phase or according to customer’s need
- Description
- Inquiry
Description
roller door roll forming machine
Roller door roll forming machine is a kind of equipment specialized in producing rolling shutter doors. It uses cold bending forming technology to bend metal sheets into the shape of rolling shutter doors. Through automated operation, the equipment can efficiently and accurately complete each process and produce rolling shutter doors of various specifications, styles and thicknesses.
1. Roller door roll forming machine adopts PLC programming automatic control technology, which can automatically complete the processes of steel plate feeding, curling, shaping, cutting, gear steel belt penetration and cutting, greatly improving production efficiency and quality.
2. Roller door roll forming machine can be used to process metal sheets of various sizes and thicknesses, and the styles of rolling shutter doors produced are also rich.
| No. | Main Parameter of roller door roll forming machine | |
| 1 | Suitable to process | Galvanized steel strips |
| 2 | Rollers | 16rollers+leveling axis 4rollers |
| 3 | Dimensions | 10500*1500*1600mm |
| 4 | Main Motor size | 11Kw*2 |
| 5 | Hydraulic pump | 5.5Kw |
| 6 | Thickness of the plate | 1.5-3.0mm |
| 7 | Productivity | 10-15m/min |
| 8 | Material of the cutting blade | Cr12Mov,Quenched treatment 58℃-60℃ |
| 9 | Diameter of the roller | Φ85mm |
| 10 | Weight | About 8.5T |
| 11 | Main structure of the machine | 450H steel |
| 12 | Processing precision | Within 2.0mm |
| 13 | Side panel of machine | 20mm |
| 14 | Chain Wheel and Cycle Chain | 2Inch |
| 15 | Voltage | 380V 50HZ 3Phase |
| 16 | Control system | PLC control (Delta) |
| 17 | Cut off the way | Hydraulic torsion shear |
| 18 | Drive mode | Motor driver |
| 19 | Hydraulic station pump | Gear pump |
| 20 | Touch screen | Delta |
| 21 | Rolling materials | Gcr15 |
| 22 | Length Tolerance | ±2mm |
roller door roll forming machine after-sales services:
1. Warranty: One year and we will provide technical support for the life of the equipment.
2. Delivery period: Within 25-45 days after receipt of the deposit of advance payment
3.Warranty period: 24-month free service / paid service for the whole life of the machine
4. Installation and training
If buyers visit our factory and review the machine, we will teach you how to install and use the machine and also train your workers / technicians face to face.
