cd and ud profile making machine
Product No: HX- steel keel
Min.Order Quantity: 1 Set
Production Cycle: 30-45 workdays
Warranty Period: 18 months
Payment Terms: T/T, Western Union, Paypal , Credit Card, Online pay
Port of Dispatch: Tianjin
Supply Ability: 100 sets per month
- Description
- Inquiry
Description
cd and ud profile making machine
Cd and ud profile making machine is equipment used to produce light steel keel (also called light steel keel or light keel). These light steel joists are commonly used in partition walls, ceilings and other supporting structures in buildings. Light steel keel machine has the following advantages：
1.Green and environmentally friendly: Light steel keel machines usually use environmentally friendly materials, and at the same time reduce the impact on the environment by optimizing the design and production process.
2.Ease of operation: Although highly automated equipment, these machines are usually designed to be easy to operate, making them easy for operators to learn and manage.
3.High production capacity: The light steel keel machine has high production capacity and can meet large-scale and high-intensity production needs.
No. | cd and ud profile making machine | |
1 | Suitable to process | Color alu-zinc steel strips |
2 | Roller | (10-14)Rows plus leveling device |
3 | Dimensions | 5.4*1*1.5m |
4 | Motor Power | 5.5Kw |
5 | Pump Station Motor | 5.5Kw.Lichao Brand |
6 | Thickness of the plate | 0.3-0.8mm |
7 | Productivity | 30-35m/min |
8 | Material of the cutting blade | Cr12,Quenched treatment 58℃-60℃ |
9 | Diameter of the roller | Φ50mm |
10 | Weight | About 2600kgs |
11 | Main structure of the machine | Square steel frame |
12 | Processing precision | Within 1.0mm |
13 | Side panel of machine | 16mm |
14 | Chain Wheel and Cycle Chain | 1 Inch |
15 | Voltage | 380V 50Hz 3phases or as customer’s need |
16 | Control system | PLC control (Delta) |
17 | Frequency system | Delta |
18 | Drive mode | Gear driver |
19 | Touch screen | Delta |
20 | Rolling materials | 45# forging steel with chromium plate |
21 | Length Tolerance | ±2mm |
Our advantage
- Machine customization
steel keel profile, Machine color, Localization of operating language and voltage, Logo design, Machine protective cover. - Inspection report
Machine inspection reports of international certification institutions, such as Bureau Veritas, are available. - After-sales service
Provide local language machine installation videos, online remote guidance, and engineer visits for adjustment and repair services. - The number of employees
5 CAD designers, 10 mechanics, 30 salesmen, 2 quality inspectors. - Warranty period
2 years - Certification of products
CE, ISO
cd and ud profile making machine after sales service
1. Warranty :Two years,and we will provide technical support for whole life of the cd and ud profile roll forming machine.
2. Delivery time: Within 25 days after deposit receipt your payment
3. Guarantee period: 24months free service/ pay service all the machine life
4. Installation and training
If buyers visit our factory and check the machine, we will teach you how to install and use the machine and also train your
workers/technician face to face.
Our other product
We have roof and wall roll forming machine, light steel keel roll forming machine,purlin roll forming machine,ridge cap roll forming machine,floor deck roll forming machine,leveling and slitting production line,bending machine,shearing machine,decoiler machine,stacker,downspout & rain gutter roll forming machine,shutter door roll forming machine,door frame roll forming machine,window frame machine,embossing machine etc.
